100GBASE-SR10 Application Overview


100GBASE‑SR10: 100 Gb/s parallel transmission at 850 nm over 20 multimode optical fibers, with reach up to at least 150 m

100GBASE‑SR10 supports short wavelength parallel transmission over ten lanes (20‑fibers) of multimode optical fiber cabling. The application’s nominal symbol rate is 10.3125 GBd per lane and the supported distance varies according to the type of multimode cable used. Network equipment interface connections include a multi‑fiber push on (MPO) connector and standard sockets into which a physical (PHY) layer transceiver module may be plugged.

  • Connector type: MPO/MTP
  • Transceiver module: CXP, CFP, CFP2, CFP4, CPAK
  • Defined in clause 86 of the IEEE 802.3 Standard for Ethernet
  • Initially published as IEEE Std 802.3ba™: Media Access Control Parameters, Physical Layers, and Management Parameters for 40 Gb/s and 100 Gb/s Operation in 2010

Optical Fiber Cabling (Channel) Characteristics:

Parameter OM3 OM4 OM5 Unit
Operating wavelength: 850 nm
Modal bandwidth (min): 2,000 4,700 MHz∙km
Operating range: 0.5 to 100 0.5 to 150 m
Insertion loss (max): 1.9 1.5 dB
Cabling skew (max): 79 ns
Cabling skew variation: 2.4 ns

Key Application Capabilities:

  • Defines a ten-lane 100 Gb/s PHY for operation over at least 100 m of MMF
  • Supports full-duplex operation only
  • Preserves the Ethernet frame format utilizing the Ethernet MAC
  • Preserves minimum and maximum FrameSize of current 802.3 Standard for Ethernet
  • Provides appropriate support for optical transport networks (OTNs)
  • Supports a BER of better than or equal to 10-12 at the MAC/PLS service interface (or the frame loss ratio equivalent)

Related Applications:

The IEEE P802.3ba Task Force also specified the following 40 Gb/s and 100 Gb/s Ethernet applications::

Application    Operating    Wavelength(s) Media Operating Range1
40GBASE-CR4 Copper Twinax up to 7 m
40GBASE-KR4 Backplane
40GBASE-LR4 four WDM2 Single-mode up to 10 km
40GBASE-SR4 850 nm Multimode up to 150 m
100GBASE-CR10 Copper Twinax up to 7 m
100GBASE-ER4 four WDM3 Single-mode up to 40 km4
100GBASE-KR10 Backplane
100GBASE-LR4 four WDM3 Single-mode up to 10 km
1 Supported distance varies according to the type of optical fiber cable used.
2 1271 nm, 1291 nm, 1311 nm, and 1331 nm
3 1295.56 nm, 1300.05 nm, 1304.58 nm, and 1309.14 nm
4 Links longer than 30 km for the same link power budget are considered engineered links and must not exceed specified insertion loss.
