200GBASE-DR4 Application Overview

by

200GBASE-DR4
200GBASE-DR4: 200 Gb/s PAM4 parallel transmission at 1310 nm over 8 single‑mode optical fibers, with reach up to at least 500 m

200GBASE-DR4 supports long wavelength 4‑level pulse amplitude modulated (PAM4) parallel transmission over four lanes (8‑fibers) of single‑mode optical fiber cabling. The application’s equivalent symbol rate is 53.125 GBd per lane (PAM4 maps pairs of bits into a single symbol) and the supported distance varies according to the type of single‑mode cable used. Network equipment interface connections include a multi-fiber push on (MPO) connector and a standard socket into which physical (PHY) layer transceiver modules may be plugged.

  • Connector type: MPO/MTP
  • Transceiver module: QSFP56
  • Defined in clause 121 of the IEEE 802.3 Standard for Ethernet
  • Initially published as IEEE Std 802.3bs™: Media Access Control Parameters, Physical Layers, and Management Parameters for 200 Gb/s and 400 Gb/s Operation in 2017


Optical Fiber Cabling (Channel) Characteristics:

200GBASE-DR4
Parameter OS1a Indoor/Outdoor OS2
Operating wavelength: 1310 nm
Insertion loss (max): 3.0 dB
Cabled fiber attenuation (max): 1.0 dB/km 0.5 dB/km 0.4 dB/km
Operating range2: 2 m to 250 m1 2 m to 500 m 2 m to 500 m
1 Operating range for cabled fibers having more than 0.5 dB/km attenuation is not specified by IEEE 802.3. This calculation is provided for information only.
2 Maximum operating ranges are calculated using a 2.75 dB connection and splice loss allocation.

Key Application Capabilities:

  • Defines a four-lane 200 Gb/s PHY for operation over at least 500 m of SMF
  • Supports full-duplex operation only
  • Preserves the Ethernet frame format utilizing the Ethernet MAC
  • Preserves minimum and maximum FrameSize of current 802.3 Standard for Ethernet
  • Provides appropriate support for optical transport networks (OTNs)
  • Supports a BER of better than or equal to 10-13 at the MAC/PLS service interface
  • Supports optional Energy-Efficient Ethernet operation

Related Applications:

The IEEE P802.3bs Task Force also specified the following 200 Gb/s and 400 Gb/s Ethernet applications:

Application    Operating    Wavelength(s) Media Operating Range1​
200GBASE-FR4 four WDM2 Single-mode up to 2 km
200GBASE-LR4 four WDM3 Single-mode up to 10 km
400GBASE-DR4 1310 nm Single-mode up to 500 m
400GBASE-FR8 eight WDM4 Single-mode up to 2 km
400GBASE-LR8 eight WDM4 Single-mode up to 10 km
400GBASE-SR16 850 nm Multimode up to 100 m
1 Supported distance varies according to the type of optical fiber cable used.
2 1271 nm, 1291 nm, 1311 nm, and 1331 nm
3 1295.56 nm, 1300.05 nm, 1304.58 nm, and 1309.14 nm
3 1273.54 nm, 1277.89 nm, 1282.26 nm, 1286.66 nm, 1295.56 nm, 1300.05 nm, 1304.58 nm, and 1309.14 nm
